Volley理解

public class DiskBasedCache implements Cache {
    /** Map of the Key, CacheHeader pairs */
    private final Map<String, CacheHeader> mEntries =
            new LinkedHashMap<String, CacheHeader>(16, .75f, true);
    /** Total amount of space currently used by the cache in bytes. */
    private long mTotalSize = 0;
    /** The root directory to use for the cache. */
    private final File mRootDirectory;
    /** The maximum size of the cache in bytes. */
    private final int mMaxCacheSizeInBytes;

    ......

    public synchronized void initialize() {
        //初始化，会读取缓存目录下的文件，全部放入mEntries中
        ...
        File[] files = mRootDirectory.listFiles();
        ...
        for (File file : files) {
            BufferedInputStream fis = null;
            try {
                fis = new BufferedInputStream(new FileInputStream(file));
                CacheHeader entry = CacheHeader.readHeader(fis);
                entry.size = file.length();
                putEntry(entry.key, entry);//重点
            } catch (IOException e) {
                ...
            } finally {
                ...
            }
        }
    }
    @Override
    public synchronized Entry get(String key) {
        CacheHeader entry = mEntries.get(key);
        // if the entry does not exist, return.
        if (entry == null) {
            return null;
        }
        File file = getFileForKey(key);
        CountingInputStream cis = null;
        try {
            cis = new CountingInputStream(new FileInputStream(file));
            CacheHeader.readHeader(cis); // eat header  //先读header
            byte[] data = streamToBytes(cis, (int) (file.length() - cis.bytesRead));
            return entry.toCacheEntry(data);//重点
        } catch (IOException e) {
            ...
        } finally {
            ...
        }
    }

    static class CacheHeader{见下代码}
    private static class CountingInputStream extends FilterInputStream {...}
}
//DiskBasedCache内部类，提出来分析 注意没有data信息
static class CacheHeader {
        /** The size of the data identified by this CacheHeader. (This is not
         * serialized to disk. */
        public long size;
        /** The key that identifies the cache entry. */
        public String key;
        /** ETag for cache coherence. */
        public String etag;
        /** Date of this response as reported by the server. */
        public long serverDate;
        /** The last modified date for the requested object. */
        public long lastModified;
        /** TTL for this record. */
        public long ttl;
        /** Soft TTL for this record. */
        public long softTtl;
        /** Headers from the response resulting in this cache entry. */
        public Map<String, String> responseHeaders;
        private CacheHeader() { }
        public CacheHeader(String key, Entry entry) {
            this.key = key;
            this.size = entry.data.length;
            this.etag = entry.etag;
            this.serverDate = entry.serverDate;
            this.lastModified = entry.lastModified;
            this.ttl = entry.ttl;
            this.softTtl = entry.softTtl;
            this.responseHeaders = entry.responseHeaders;
        }

	public static CacheHeader readHeader(InputStream is) throws IOException{...}
	public boolean writeHeader(OutputStream os){...}
	public Entry toCacheEntry(byte[] data){
            Entry e = new Entry();
            e.data = data;
            e.etag = etag;
            e.serverDate = serverDate;
            e.lastModified = lastModified;
            e.ttl = ttl;
            e.softTtl = softTtl;
            e.responseHeaders = responseHeaders;
            return e;
    }
}

public interface Cache {
    public Entry get(String key);
    public void put(String key, Entry entry);
    public void initialize();
    public void invalidate(String key, boolean fullExpire);
    public void remove(String key);
    public void clear();
    public static class Entry {
        /** The data returned from cache. */
        public byte[] data;
        /** ETag for cache coherency. */
        public String etag;
        /** Date of this response as reported by the server. */
        public long serverDate;
        /** The last modified date for the requested object. */
        public long lastModified;
        /** TTL for this record. */
        public long ttl;
        /** Soft TTL for this record. */
        public long softTtl;
        /** Immutable response headers as received from server; must be non-null. */
        public Map<String, String> responseHeaders = Collections.emptyMap();
        /** True if the entry is expired. */
        public boolean isExpired() {
            return this.ttl < System.currentTimeMillis();
        }
        /** True if a refresh is needed from the original data source. */
        public boolean refreshNeeded() {
            return this.softTtl < System.currentTimeMillis();
        }
    }
}

private final Map<String, CacheHeader> mEntries =
            new LinkedHashMap<String, CacheHeader>(16, .75f, true);
//重点，这个true是设置成access order， false是insertion order
/**
 * Puts the entry with the specified key into the cache.
 */
@Override
public synchronized void put(String key, Entry entry) {
    pruneIfNeeded(entry.data.length);
    File file = getFileForKey(key);
    try {
        BufferedOutputStream fos = new BufferedOutputStream(new FileOutputStream(file));
        CacheHeader e = new CacheHeader(key, entry);
        boolean success = e.writeHeader(fos);
        if (!success) {
            fos.close();
            VolleyLog.d("Failed to write header for %s", file.getAbsolutePath());
            throw new IOException();
        }
        fos.write(entry.data);
        fos.close();
        putEntry(key, e);
        return;
    } catch (IOException e) {
    }
    boolean deleted = file.delete();
    if (!deleted) {
        VolleyLog.d("Could not clean up file %s", file.getAbsolutePath());
    }
}
    /**
     * Prunes the cache to fit the amount of bytes specified.
     * @param neededSpace The amount of bytes we are trying to fit into the cache.
     */
    private void pruneIfNeeded(int neededSpace) {
        if ((mTotalSize + neededSpace) < mMaxCacheSizeInBytes) {
            return;
        }
        if (VolleyLog.DEBUG) {
            VolleyLog.v("Pruning old cache entries.");
        }
        long before = mTotalSize;
        int prunedFiles = 0;
        long startTime = SystemClock.elapsedRealtime();
        Iterator<Map.Entry<String, CacheHeader>> iterator = mEntries.entrySet().iterator();
        while (iterator.hasNext()) {
            //从头开始删除，linkedhashmap又是access order ,所以是LRU
            Map.Entry<String, CacheHeader> entry = iterator.next();
            CacheHeader e = entry.getValue();
            boolean deleted = getFileForKey(e.key).delete();
            if (deleted) {
                mTotalSize -= e.size;
            } else {
               VolleyLog.d("Could not delete cache entry for key=%s, filename=%s",
                       e.key, getFilenameForKey(e.key));
            }
            iterator.remove();
            prunedFiles++;
            if ((mTotalSize + neededSpace) < mMaxCacheSizeInBytes * HYSTERESIS_FACTOR) {
                break;
            }
        }
        if (VolleyLog.DEBUG) {
            VolleyLog.v("pruned %d files, %d bytes, %d ms",
                    prunedFiles, (mTotalSize - before), SystemClock.elapsedRealtime() - startTime);
        }
    }

//NetworkDispatcher.java
public class NetworkDispatcher extends Thread {
    /** The queue of requests to service. */
    private final BlockingQueue<Request<?>> mQueue;
    /** The network interface for processing requests. */
    private final Network mNetwork;
    /** The cache to write to. */
    private final Cache mCache;
    /** For posting responses and errors. */
    private final ResponseDelivery mDelivery;
    /** Used for telling us to die. */
    private volatile boolean mQuit = false;

    ...

    @Override
    public void run() {
        Process.setThreadPriority(Process.THREAD_PRIORITY_BACKGROUND);
        while (true) {
            long startTimeMs = SystemClock.elapsedRealtime();
            Request<?> request;
            try {
                // Take a request from the queue.
                request = mQueue.take();
            } catch ...
            try {
                request.addMarker("network-queue-take");
                // If the request was cancelled already, do not perform the
                // network request.
                if (request.isCanceled()) {
                    request.finish("network-discard-cancelled");
                    continue;
                }
                addTrafficStatsTag(request);
                // Perform the network request.
                NetworkResponse networkResponse = mNetwork.performRequest(request);//发起请求
                request.addMarker("network-http-complete");
                // If the server returned 304 AND we delivered a response already,
                // we're done -- don't deliver a second identical response.
                if (networkResponse.notModified && request.hasHadResponseDelivered()) {
                    request.finish("not-modified");
                    continue;
                }
                // Parse the response here on the worker thread.
                Response<?> response = request.parseNetworkResponse(networkResponse);//转1 目的在于构建Cache.Entry
                request.addMarker("network-parse-complete");
                // Write to cache if applicable.
                // TODO: Only update cache metadata instead of entire record for 304s.
                if (request.shouldCache() && response.cacheEntry != null) {
                    mCache.put(request.getCacheKey(), response.cacheEntry);//放入mCache中（cacheHeader），同时保存在磁盘中（这个方法在上文FIFO/LRU讨论有提及）
                    request.addMarker("network-cache-written");
                }
                // Post the response back.
                request.markDelivered();
                mDelivery.postResponse(request, response);
            } catch ...
        }
    }

    //其他方法
}
//Request.java
//接 转1
public abstract class Request<T> implements Comparable<Request<T>> {
    ...
 	//在具体的Request类中实现，这里以JsonObjectRequest类为例，见下代码
	abstract protected Response<T> parseNetworkResponse(NetworkResponse response);
    ...
}
//JsonObjectRequest.java 以JsonObjectRequest的实现为例
public class JsonObjectRequest extends JsonRequest<JSONObject> {
    public JsonObjectRequest(int method, String url, JSONObject jsonRequest,
            Listener<JSONObject> listener, ErrorListener errorListener) {
        super(method, url, (jsonRequest == null) ? null : jsonRequest.toString(), listener,
                    errorListener);
    }
    ...
    //实现抽象方法
    @Override
    protected Response<JSONObject> parseNetworkResponse(NetworkResponse response) {
        try {
            String jsonString = new String(response.data,
                    HttpHeaderParser.parseCharset(response.headers, PROTOCOL_CHARSET));
            // HttpHeaderParser.parseCacheHeaders() -> 完成response的header解析,构建成Cache.Entry（这是有数据的）
            // Response.success() -> new Response<T>(T result, Cache.Entry cacheEntry);
            return Response.success(new JSONObject(jsonString),
                    HttpHeaderParser.parseCacheHeaders(response));//静态方法
        } catch (UnsupportedEncodingException e) {
            return Response.error(new ParseError(e));
        } catch (JSONException je) {
            return Response.error(new ParseError(je));
        }
    }
}
//HttpHeaderParser.java
public class HttpHeaderParser {
    public static Cache.Entry parseCacheHeaders(NetworkResponse response) {
        long now = System.currentTimeMillis();
        Map<String, String> headers = response.headers;
        long serverDate = 0;
        long lastModified = 0;
        long serverExpires = 0;
        long softExpire = 0;
        long finalExpire = 0;
        long maxAge = 0;
        long staleWhileRevalidate = 0;
        boolean hasCacheControl = false;
        boolean mustRevalidate = false;
        String serverEtag = null;
        String headerValue;
        headerValue = headers.get("Date");
        if (headerValue != null) {
            serverDate = parseDateAsEpoch(headerValue);
        }
        headerValue = headers.get("Cache-Control");
        if (headerValue != null) {
            hasCacheControl = true;
            String[] tokens = headerValue.split(",");
            for (int i = 0; i < tokens.length; i++) {
                String token = tokens[i].trim();
                if (token.equals("no-cache") || token.equals("no-store")) {
                    return null;
                } else if (token.startsWith("max-age=")) {
                    try {
                        maxAge = Long.parseLong(token.substring(8));
                    } catch (Exception e) {
                    }
                } else if (token.startsWith("stale-while-revalidate=")) {
                    try {
                        staleWhileRevalidate = Long.parseLong(token.substring(23));
                    } catch (Exception e) {
                    }
                } else if (token.equals("must-revalidate") || token.equals("proxy-revalidate")) {
                    mustRevalidate = true;
                }
            }
        }
        headerValue = headers.get("Expires");
        if (headerValue != null) {
            serverExpires = parseDateAsEpoch(headerValue);
        }
        headerValue = headers.get("Last-Modified");
        if (headerValue != null) {
            lastModified = parseDateAsEpoch(headerValue);
        }
        serverEtag = headers.get("ETag");
        // Cache-Control takes precedence over an Expires header, even if both exist and Expires
        // is more restrictive.
        if (hasCacheControl) {
            softExpire = now + maxAge * 1000;
            finalExpire = mustRevalidate
                    ? softExpire
                    : softExpire + staleWhileRevalidate * 1000;
        } else if (serverDate > 0 && serverExpires >= serverDate) {
            // Default semantic for Expire header in HTTP specification is softExpire.
            softExpire = now + (serverExpires - serverDate);
            finalExpire = softExpire;
        }
        Cache.Entry entry = new Cache.Entry();
        entry.data = response.data;
        entry.etag = serverEtag;
        entry.softTtl = softExpire;
        entry.ttl = finalExpire;
        entry.serverDate = serverDate;
        entry.lastModified = lastModified;
        entry.responseHeaders = headers;
        return entry;
    }

	...
}

public class CacheDispatcher extends Thread {
	...

	@Override
    public void run() {
        if (DEBUG) VolleyLog.v("start new dispatcher");
        Process.setThreadPriority(Process.THREAD_PRIORITY_BACKGROUND);
        // Make a blocking call to initialize the cache.
        mCache.initialize();
        while (true) {
            try {
                // Get a request from the cache triage queue, blocking until
                // at least one is available.
                final Request<?> request = mCacheQueue.take();
                request.addMarker("cache-queue-take");
                // If the request has been canceled, don't bother dispatching it.
                if (request.isCanceled()) {
                    request.finish("cache-discard-canceled");
                    continue;
                }
                // Attempt to retrieve this item from cache.
                Cache.Entry entry = mCache.get(request.getCacheKey());
                if (entry == null) {
                    request.addMarker("cache-miss");
                    // Cache miss; send off to the network dispatcher.
                    mNetworkQueue.put(request);
                    continue;
                }
                // If it is completely expired, just send it to the network.
                if (entry.isExpired()) {
                    // ttl过期，彻底过期，直接走网络
                    request.addMarker("cache-hit-expired");
                    request.setCacheEntry(entry);
                    mNetworkQueue.put(request);
                    continue;
                }
                // We have a cache hit; parse its data for delivery back to the request.
                request.addMarker("cache-hit");
                Response<?> response = request.parseNetworkResponse(
                        new NetworkResponse(entry.data, entry.responseHeaders));
                request.addMarker("cache-hit-parsed");
                if (!entry.refreshNeeded()) {
                    // Completely unexpired cache hit. Just deliver the response.
                    // 完全没过期
                    mDelivery.postResponse(request, response);
                } else {
                    // Soft-expired cache hit. We can deliver the cached response,
                    // but we need to also send the request to the network for
                    // refreshing.
                    // softTtl过期，先返回请求；再去网络请求
                    request.addMarker("cache-hit-refresh-needed");
                    request.setCacheEntry(entry);
                    // Mark the response as intermediate.
                    response.intermediate = true;
                    // Post the intermediate response back to the user and have
                    // the delivery then forward the request along to the network.
                    mDelivery.postResponse(request, response, new Runnable() {
                        @Override
                        public void run() {
                            try {
                                mNetworkQueue.put(request);
                            } catch (InterruptedException e) {
                                // Not much we can do about this.
                            }
                        }
                    });
                }
            } catch (InterruptedException e) {
                // We may have been interrupted because it was time to quit.
                if (mQuit) {
                    return;
                }
                continue;
            }
        }
    }

}
